Rega

Rega Ania MC Cartridge

Rega Ania MC Cartridge

Regular price $1,199.00 AUD
Regular price Sale price $1,199.00 AUD
Sale Sold out
Shipping calculated at checkout.

Rega Ania MC Cartridge

The Ania was inspired by the success of our Apheta and Aphelion MC models. Ania uses the same complex hand wound micro coil found in the rest of the range, and is housed in a unique PPS highly rigid body. This body is an exceptionally accurate design that includes Rega’s three point fixing to optimise connection to the tonearm headshell and automatically sets overhang when fitted to a Rega tonearm. The new body is protected by a CAD designed, clear rigid cover to protect the internal fine wires, making handling whilst fitting, safe and risk free. The Ania features a super high-powered, neodymium magnet and a coil meticulously hand wound on to an iron micro cross. This miniature assembly allows us greater freedom to track the vinyl groove ensuring even more detail is extracted from the vinyl.

Welcome to the world of moving coils

Rega’s Moving Coil cartridge design is unique in its approach to achieving an ultra-low mass generator which is undamped (no tie wire) using a unique rhomboid pivot for the cantilever powered by a purpose designed, exclusive to Rega, Neodymium magnet system. This type of design requires a zero-tolerance engineered cartridge body which is Rega’s area of expertise and with the Apheta 3 and Aphelion 2 products these bodies are machined from one piece of the highest quality aluminium. This is a difficult and expensive process requiring all of Rega’s years of experience to achieve. In particular, the “zero” tolerancing of the body is required in the alignment and dimension of the pivot pad mounting hole and the magnet mechanism mounting hole relationship.

KEY FEATURES

  • Iron micro cross assembly
  • One of the worlds smallest MC generators
  • Cutting edge high power Neodymium magnets
  • Elliptical profile stylus
  • Aluminium cantilver
  • Coil constructed from 0.018 mm fine wire
  • Lifetime warranty against manufacture defects

Specifications

  • Tracking Pressure: 1.75 - 2.00 g
  • Input Load Impedance: 100 Ω
  • Output Impedance: 10 Ω
  • Nominal output voltage: 350 μV
  • Channel Balance: ≥ 20 μV
  • Separation: ≥ -29 dB
