Rega Fono MC Mk4

Rega Fono MC Mk4

The Fono MC MK4 is an exceptionally high quality MC phono stage designed to maximise the potential of any low output MC cartridge. Although specifically designed to complement the latest Rega range of moving coils you will find full adjustability for gain and loading via dip switches conveniently placed on the rear panel making the Fono MC MK4 compatible with a wide range of third party low output MC cartridges. Now housed in a brand new redesigned case to match the new Fono MM MK5 and Neo MK2 and Rega’s latest range of electronic components offering a modern look guaranteed to integrate in to any hi-fi system.

KEY FEATURES

• Dedicated moving coil phono stage
• Simple connectivity and operation
• Fully adjustable via DIP switches via rear panel
• MUSE operational amplifier used in RIAA equalization amplifer
• Two selectable gain settings
• Default factory settings matched for all Rega MC models
• Latest design custom casework
• Lifetime warranty against manufacture defects

SPECIFICATIONS

• Output Impedance: 200 Ω
• Recommended Minimum Output Load Resistance: 5 k
• Frequency Response (50 kΩ Output Load): 13 Hz (-3 dB) to 100 kHz (-0.3 dB)
• RIAA Accuracy (50 kΩ Output Load): Better than ±0.2 dB 100 Hz to 100 kHz
• Power Requirements: 24 V AC at 150 mA maximum

LOAD SETTINGS FOR ADJUSTABLE MC STAGES

• Input Sensitivity (for 200 mV Output): 4 off = 133 uV / 4 on = 67 uV
• Input Loading Resistance: 1 and 2 off = 400 Ω / 1 on = 100 Ω / 2 on = 150 Ω / 1 and 2 on = 70 Ω
• Input Loading Capacitance: 3 off = 1000 pF / 3 on = 4300 pF / Gain (at 1 kHz) / 4 off = 63.5 dB / 4 on = 69.5 dB
• Maximum Input Level (at 1 kHz): 4 off = 6.7 mV / 4 on = 3.4 mV
• Factory settings for all Rega MC cartridges: Impedance 100 Ω / Capacitance 1000 pF / Gain Setting High
